GST CERTIFICATE OCR API
EXTRACT TEXT FROM GST CERTIFICATE IMAGES
Description
This API can extract and parse the text from an input GST certificate document image and return the information in JSON format. This API can parse both provisional and registered GST certificates.

API Outcome
- GSTIN Number
- Legal and trade name of individual / entity
- Date of registration
- PAN, TIN and Central sales tax registration number if available
- Type of registration
- Address as registered
API Details
Request
Type | URL |
---|---|
Post | https://api.attestr.com/api/{version}/public/xtract |
Request Body Parameters
Type | Name | Description | Optional (Default) | Min Version | Max Version |
---|---|---|---|---|---|
String | src | Input GST certificate image media Id. To generate a media Id, refer to Image Media Upload | Required | v1 | |
String | additional | Document back side image media Id. | Optional | v1 | |
String | type | Pass constant value as GST | Required | v1 |
Request Header Parameters
Type | Name | Value / Description | Optional (Default) | Min Version | Max Version |
---|---|---|---|---|---|
String | Content-Type | application/json | Required | v1 | |
String | Authorization | Basic {authToken} | Required | v1 |
If you do not have the authentication token, please refer to Register App to generate one.
Sample Request
{
"src":"MX1AloEdDOB7Xgc00d",
"additional": null,
"type": "GST"
}
Response
Http Status Code 200
Please note that the valid key decides the availability of rest of the keys in the response. If provided PAN image is invalid or low quality, then all keys except valid and message are omitted. If true, remaining keys will have appropriate data.
Key | Description | Type | Min Version | Max Version |
---|---|---|---|---|
valid | True | false if the provided GST certificate image is a valid readable document with decent quality | Boolean | v1 | |
data | GST Object as described below | Object | v1 | |
message | Message string if the input media image is invalid or of not enough good quality to be read by OCR algorithm | String | v1 |
GST Object
Key | Description | Type | Min Version | Max Version |
---|---|---|---|---|
gstin | GSTIN number as present on the card | String | v1 | |
legalName | Legal entity name as registered. | String | v1 | |
tradeName | Trade / business name if available. | String | v1 | |
constitution | Constitution of the entity such as private limited, proprietorship etc. | Date | v1 | |
address | Primary address of the entity | Date | v1 | |
type | Registration type eg Regular, composition etc. | String | v1 | |
registered | Date of registration DD/MM/YYYY | Date | v1 | |
expiry | Date of expiry if available DD/MM/YYYY | Date | v1 | |
issued | Date of issue of the certificate DD/MM/YYYY | Date | v1 | |
approvingAuthority | Approving authority | String | v1 | |
jurisdiction | Jurisdiction code of the GST office when entity is registered | String | v1 | |
provisional | Boolean flag indicating if the certificate registration is provisional or permanent. | Boolean | v1 | |
pan | PAN number of the entity. Available for provisional certificate only. | String | v1 | |
tin | TIN (Tax information network) Id. Available for provisional certificate only. | String | v1 | |
slr | Central sales tax registration number. Available for provisional certificate only. | String | v1 |
Sample Response
Sample response for valid registered GST certificate
{
"valid": true,
"message": null,
"data":{
"gstin": "24ABCD1234R1ZN",
"legalName": "ACME INFO PRIVATE LIMITED",
"tradeName": "ACME INFO PRIVATE LIMITED",
"constitution": "Private Limited Company",
"address": "10th Floor, 1006, Road, Ahmedabad, B Square-1, Gujarat, Near Neptune House, 380058 Ambli Brts,",
"type": "Regular",
"registered": "30/03/2021",
"expiry": null,
"issued": "30/03/2021",
"approvingAuthority": "Gujarat",
"jurisdiction": "Ghatak 11 (Ahmedabad)",
"provisional": false,
"pan": null,
"tin": null,
"slr": null
}
}
Sample response for a valid provisional GST certificate
{
"valid": true,
"message": null,
"data": {
"gstin": "27AABCD1168D1ZM",
"legalName": "ACME INFO TRUST MAHARASHTRA",
"tradeName": "ACME INFO TRUST MAH.",
"constitution": null,
"address": null,
"type": null,
"registered": null,
"expiry": null,
"issued": null,
"approvingAuthority": null,
"jurisdiction": null,
"provisional": true,
"pan": "ABCDS1168D",
"tin": "275xxxxxx016v",
"slr": "275xxxxxxx16c"
}
}
Sample response for invalid document image
{
"valid": false,
"message": "Invalid / low quality image"
}
Error Response
Parameter | Type | Description |
---|---|---|
code | Number | Unique error codes for different errors. Always available. |
message | String | Error message describing the error. Always Available. |
details | String | Detail error message. Available only for certain types of errors. |
Error Codes
HTTP Status | Error Code | Error Message |
---|---|---|
400 | 4001 | Malformed data or missing required parameter values |
400 | 4005 | Operation could not be performed due to low credits balance |
401 | 4016 | Invalid client authorization |
403 | 4031 | Unauthorized access |
403 | 4035 | Requested service is not provisioned for your account |
403 | 4039 | Client's IP address is not whitelisted |
403 | 4035 | Requested service is not provisioned for your account |
429 | 4291 | Maximum account rate limit exceeded |
429 | 4292 | Maximum API rate limit exceeded |
429 | 4293 | Maximum account daily limit exceeded |
429 | 4294 | Maximum API daily limit exceeded |
500 | 5001 | Request could not be processed |
Sample Error Response
{
"code": 4001,
"message": "Malformed data or missing required parameter values"
}
Constraints
- Only JPEG, PNG images are supported.
- Minimum image size is 200x200 png for better identification and parsing.
- Maximum allowed image size is 10 MB.
